INCH-POUND
MIL-DTL-15098/3B
23 August 2010
SUPERSEDING
MIL-L-15098/3A
14 December 1973
DETAIL SPECIFICATION SHEET
LAMPS, GLOW, INDICATOR, TYPES W1A AND R2A
This specification is approved for use by all Departments and Agencies of the Department of
Defense.
The requirements for acquiring the product described herein shall consist of this specification
sheet and MIL-DTL-15098, "Lamps, Glow, General Specification for".
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only and are based upon 1 inch = 25.4 mm.
FIGURE 1. Indicator glow lamp, types W1A and R2A.
REQUIREMENTS:
Design and configuration: See figure 1 and table I.
Vibration: Not applicable.
Shock: Method II of MIL-DTL-15098.
Part number: M15098/3 - (Dash number from table I).
AMSC N/A
FSC 6240
