MIL-DTL-15098/3B
TABLE I. Dash numbers and characteristics.
Dash no.
001
002
Characteristic
Bulb shape and size
S14
S14
Maximum overall length (inches)
3.500
3.500
Base
M
M
Electrode shape
P2
P2
Distance from end of electrode to end of bulb
1.125
1.125
(inches, nominal)
Series resistor
Ohms (nominal)
3,500
3,500
Location
In base
In base
Characteristic gas
Argon
Neon
Glow color
Blue
Red
Watts (nominal)
2
2
Application
Indicator
Indicator
Circuit volts
105 - 125 AC
105 - 125 AC
Maximum initial starting voltage (volts)
In light (maximum)
75 AC, 110 DC
65 AC, 90 DC
Design current (milliamperes)
18
18
Initial light output (lumens)
Not applicable
0.75
Average life at design current (hours)
Not applicable
10,000
Industry number
ANSI
W1A
R2A
Former lamp number
AR-1
NE-34
CHANGES FROM PREVIOUS ISSUE. Marginal notations are not used in this revision to
identify changes with respect to the previous issue due to the extent of the changes.
2
