MIL-DTL-15098/4C
TABLE I. Characteristics and specifications.
Characteristic
Specification
Bulb shape and size
S11
Maximum overall length (inches)
2.250
Base
M
Electrode shape
PW5
Distance from end of electrode to end of bulb
0.500
(inches, nominal)
Series resistor
Ohms (nominal)
7,500
Location
In base
Characteristic gas
Neon
Glow color
Red
Watts (nominal)
1
Application
Indicator
Nominal circuit voltage (volts)
120 AC
Maximum initial starting voltage (volts)
In light
65 AC, 90 DC
Design current (milliamperes)
8
Average life at design current (hours)
10,000
Industry number
ANSI
J5A
Former lamp number
NE-30
CHANGES FROM PREVIOUS ISSUE. Marginal notations are not used in this revision to
identify changes with respect to the previous issue due to the extent of the changes.
2
