MIL-DTL-15098/9C
REQUIREMENTS:
Design and configuration: See figure 1 and table I.
Vibration: Not applicable.
Shock: Method II of MIL-DTL-15098.
Part number: M15098/9 - 001.
TABLE I. Characteristics and specifications.
Characteristic
Specification
Bulb shape and size
S14
Maximum overall length (inch)
3.938
Base
DCBS
Electrode shape
P4
Distance from end of electrode to end of bulb
0.875
(inches, nominal)
Series resistor
Ohms
2,200
Location
External
Characteristic gas
Neon
Glow color
Red
Watts (nominal)
3
Application
Indicator
Nominal circuit voltage (volts)
120 AC
Maximum initial starting voltage (volts)
In light
60 AC, 85 DC
Design current (milliamperes)
25
Initial light output (lumens)
1.15
Average life at design current (hours)
10,000
Industry number
ANSI
R9A
Former industry number
NE-42
CHANGES FROM PREVIOUS ISSUE. Marginal notations are not used in this revision to
identify changes with respect to the previous issue due to the extent of the changes.
3
