MIL-DTL-6363/10A
NOTES:
1.
Dimensions are in inches
2.
Intended use - aircraft indicator and interior lighting applications.
3.
For design feature purposes, This specification takes precedence over procurement
documents referenced herein.
4.
Qualification by similarity - Lamp M6363/10-1 may be qualified by similarity and
extension of qualification from M6363/11-2 with no additional testing. Refer to
MIL-DTD-6363 for conditions and data requirements for qualification.
REQUIREMENTS:
1.
Configuration and dimensions: See figure 1.
2.
Finish: Glass globe finish shall be as indicated in table I.
TABLE I. Part or identifying numbers (PIN) and operating characteristics.
Part or
Type
Bulb
Shock
Filament
MSCD
Average
±25%
Identifying
MIL-
Fin-
Test
Electrical Ratings
Style
Rated Lab
Number
DTL-
ish
Level
Volts
Amperes Watts
Life at DC
(±10%) (Max)
(PIN)
6363
(G's)
(Nom)
Candelas
Hours
M6363/10-1
I
Clear
50
28.0
0.17
5.32
C-2F
3
500
3.
Lamp operating characteristics: When operated at rated voltage, the lamp operating
characteristics shall be as specified in table I.
4.
Coating adhesion: Not applicable.
High temperature: Applicable for qualification tests only (85°C/185F°).
5.
6.
Thermal shock: Applicable for qualification tests only. Use temperatures for Type I
lamps.
7.
Random vibration: Applicable for qualification tests only. See figure 2 for random
vibration curve.
8.
Shock: Applicable for qualification tests only. See table I for applicable "g" level.
9.
Humidity: Applicable for qualification tests only.
10.
Salt spray: Applicable for qualification tests only.
2
