MIL-DTL-6363/7A
NOTES:
Dimensions are in inches. Unless otherwise specified, tolerances: decimals ±0.015 inch.
1.
2.
Threads shall be in accordance with FED STD-H28.
3.
Intended use - aircraft instrument and indicator assemblies.
4.
For design feature purposes, this specification takes precedence over procurement
documents referenced herein.
5.
Qualification by similarity - Lamp M6363/7-3 is required to be fully qualified in
accordance with table I of MIL-DTL-6363. All other lamps may be granted qualification
by similarity and extension of qualification from M6363/7-3 with no additional testing.
Red lamp M6363/7-1R may be granted qualification status based upon qualification
approval of the -3R lamp. Refer to MIL-DTD-6363 for conditions and data requirements
for qualification.
REQUIREMENTS:
1.
Configuration and dimensions: See figure 1.
2.
Finish: Glass globe finish shall be as indicated in table I. Red lamps shall conform to
MIL-C-25050 for instrument and panel lighting red.
TABLE I. Part or identifying numbers (PIN) and operating characteristics.
Part or
Type
Bulb
Shock
Filament
MSCD
Average
±25% 1/
Identifying
MIL-
Fin-
Test
Electrical Ratings
Style
Rated Lab
Number
DTL-
ish
Level
Volts
Amperes Watts
Life at DC
(±10%) (Max)
(PIN)
6363
(G's)
(Nom)
Candelas
Hours
M6363/7-1
Clear
3.0
0.19
0.06
C-2R
0.25
350
M6363/7-1R
Red
3.0
0.19
0.06
C-2R
0.25
350
M6363/7-2
I
Clear
50
6.0
0.20
0.13
C-2R
0.63
1,000
M6363/7-3
Clear
28.0
0.04
1.12
C-2F
0.34
1,000
M6363/7-3R
Red
28.0
0.04
1.12
C-2F
0.34
1,000
1/ MSCD for colored lamps applies to clear lamp before coating is applied.
3.
Lamp operating characteristics: When operating at rated voltage, the lamp operating
characteristics shall be as specified in table I.
4.
Coating adhesion: Applicable to exterior coated colored lamps.
High temperature: Applicable for qualification tests only (85°C/185F°).
5.
6.
Thermal shock: Applicable for qualification tests only. Use temperatures for Type I
lamps..
2
