INCH-POUND
MIL-DTL-15098/1C
23 August 2010
SUPERSEDING
MIL-L-15098/1B
16 December 1977
DETAIL SPECIFICATION SHEET
LAMPS, GLOW, INDICATOR, TYPES A9A-T, C2A-T, AND A2A-T
This specification is approved for use by all Departments and Agencies of the Department of
Defense.
The requirements for acquiring the product described herein shall consist of this specification
sheet and MIL-DTL-15098, "Lamps, Glow, General Specification for".
NOTE:
1. Except as noted, dimensions are in inches.
FIGURE 1. Indicator glow lamp, types A9A-T, C2A-T, and A2A-T.
REQUIREMENTS:
Design and configuration: See figure 1 and table I.
Bulbs: Form tipped.
Vibration: Applicable.
Shock: Method I of MIL-DTL-15098.
Part number: M15098/1 - (Dash number from table I).
AMSC N/A
FSC 6240
