MIL-DTL-15098/1C
TABLE I. Dash numbers and characteristics.
Dash no.
001
002
003
Characteristic
Bulb, T2, diameter (inch, maximum)
0.244
0.244
0.244
Bulb, length (inch, maximum)
0.750
0.750
0.844
Base
NB
NB
NB
Electrode shape
W11
W11
W11
Electrode length (millimeters, minimum)
7.0
7.0
7.0
End of electrode to bulb tip (inch, nominal)
0.312
0.312
0.375
Lead length (inch)
2 ±0.062
2 ±0.062
2 ±0.062
Characteristic gas
Neon
Neon
Neon
Glow color
Red
Red
Red
Series resistor
Ohms
100,000
30,000
100,000
Location
External
External
External
Application
Indicator
Indicator
Indicator
Brightness
Standard
High
Standard
Watts, nominal
0.083
0.250
0.066
Nominal circuit voltage (volts)
120 AC
120 AC,
120 AC
150 DC
Maximum initial starting voltage (volts)
In light
65 AC, 90 DC
95 AC, 135 DC
65 AC, 90 DC
In dark
75 AC
105 AC
75 AC
Design current (milliamperes)
0.7
1.9
0.8
Initial light output (lumens per square foot)
0.03
0.20
0.032
Average life at design current (hours)
25,000
25,000
25,000
Industry numbers
ANSI
A9A-T
C2A-T
A2A-T
Former lamp number
NE-2ET
NE-2HT
NE-2AT
