MIL-DTL-15098/11C
REQUIREMENTS:
Design and construction: See figure 1 and table I.
Vibration: See table I.
Shock: Method II of MIL-DTL-15098.
Part number: M15098/11 - (Dash number from table I).
TABLE I. Dash numbers and characteristics.
Dash no.
Characteristic
001
002
003
004
Bulbs shape and size
T2
T2
T2
T2
Maximum overall length (inch)
0.938
0.938
0.755
0.755
Base
SMF
SMF
SMF
SMF
Electrode shape
W11
W11
W11
W11
Electrode length (millimeter,
7
7
5
5
nominal)
Distance from end of electrode
0.188
0.188
0.156
0.156
to end of bulb (inch, nominal)
Series resistor
Ohms
100,000
30,000
220,000
47,000
Location
External
External
External
External
Characteristic gas
Neon
Neon
Neon
Neon
Glow color
Red
Red
Red
Red
Watts (nominal)
0.083
0.250
0.040
0.144
Application
Indicator
Indicator
Indicator
Indicator
Brightness
Standard
High
Standard
High
Nominal circuit voltage (volts)
120 AC
120 AC,
120 AC or DC
120 AC,
150 DC
150 DC
Maximum voltage (volts)
65 AC,
95 AC,
65 AC, 90 DC 95 AC,
90 DC
135 DC
135 DC
Design current (milliamperes)
0.7
1.9
0.3
1.2
Initial light output (lumens)
0.03
0.20
0.020
0.100
Vibration
Not applicable Not applicable
Applicable
Applicable
Average life at design current
25,000
25,000
25,000
25,000
(hours)
Industry number
ANSI
C7A
C9A
A1G
A1H
Former lamp number
NE-2D
NE-2J
-
-
CHANGES FROM PREVIOUS ISSUE. Marginal notations are not used in this revision to
identify changes with respect to the previous issue due to the extent of the changes.
