MIL-DTL-6363/6A
TABLE I. Part or identifying numbers (PIN) and operating characteristics.
Part or
Type
Bulb
Shock
Filament
MSCD
Average
Identifying
MIL-
Fin-
Test
Electrical Ratings
Style
Rated Lab
Number (PIN)
DTL-
ish
Level
Volts
Amperes Watts
Life at DC
(±10%) (Max)
(SEE REQT 2)
6363
(G's)
(Nom)
Candelas
Hours
0.03±25%
M6363./6-1
Clear
5.0
0.06
0.33
C-2R
30,000
0.03±15%
M6363/6-1 AS15
Clear
5.0
0.06
0.33
C-2R
30,000
0.05±25%
M6363/6-2
Clear
5.0
0.06
0.33
C-2R
20,000
0.05±15%
M6363/6-2 AS15
Clear
5.0
0.06
0.33
C-2R
20,000
0.15±25%
M6363/6-3
I
Clear
50
5.0
0.06
0.33
C-2R
2,000
0.15±15%
M6363/6-3 AS15
Clear
5.0
0.06
0.33
C-2R
2,000
0.15±25%
M6363/6-4
Clear
5.0
0.115
0.63
C-2R
20,000
0.15±15%
M6363/6-4 AS15
Clear
5.0
0.115
0.63
C-2R
20,000
0.13±25%
M6363/6-5
Clear
28.0
0.024
0.74
CC-2F
4,000
0.13±15%
M6363/6-4 AS15
Clear
28.0
0.024
0.74
CC-2F
4,000
6.
MSCD at 1,000 hours shall be not less than 80 percent of initial MSCD when measured at
rated voltage..
7.
Coating adhesion: Not applicable.
High temperature: Applicable for qualification tests only (85°C/185F°).
8.
9.
Thermal shock: Applicable for qualification tests only. Use temperatures for Type I
lamps.
10.
Random vibration: Applicable for qualification tests only. See figure 2 for random
vibration curve.
11.
Shock: Applicable for qualification tests only. See table I for applicable "g" level.
12.
Humidity: Applicable. for qualification tests only.
13.
Salt spray: Applicable for qualification tests only.
14.
Marking: Production lamps qualified to MIL-DTL-6363 and listed on QPL-6363 shall be
marked in accordance with ANSI-C78.390 and as supplemented herein. ANSI-C78.390
authorized suffix letters shall be supplemented with the letter "Q" (MIL-DTL-6363 QPL
item). The letter "Q" shall be incorporated into the method of designation in accordance
with the preferred marking below:
3
