A-A-52409A
Army
Rated
Rated
Design
Former
Filament
former
avg. lab
PIN no.
MS part no.
type
part no.
Volts Watts
Volts
Amps
life
AA52409-4863
MS18008-4863 7998618
24
80/60
28/28
2.86/2.14 CC6/CC6
400 hrs.
Description: Clear glass prismatic lens, PAR56, filament shield
NOTES:
1. Dimensions are in inches.
2. Tolerances are ±.010 unless otherwise specified.
3. Boot material shall be made of rubber.
4. The 3 cables shall be made of 14 gauge wire.
5. Contact pins to be used shall be in accordance with A-A-52536, "Contact, Electrical No. 12, 14, and
16 A.W.G.".
FIGURE 3. Incandescent sealed beam headlamp, 3-cable type.
