A-A-52409A
Rated
Design
Filament
Rated avg.
Former
type
lab life
PIN no.
MS part no.
Volts
Watts
Volts
Amps
AA52409-4801
MS18010-4801
24
80/60
28/28
2.86/2.14
CC6/CC6
400 hrs.
Description: Clear glass prismatic lens, PAR56, filament shield
NOTES:
1. Dimensions are in inches.
2. Tolerances are ±.010 unless otherwise specified.
FIGURE 4. Incandescent sealed beam headlamp, 3-contact lug type.
7
